- Strong mast material ensure high capacity
- Explosion-proof valve in the pump, to avoid rapid decline to protect the operator
- Over-discharge protection device greatly extends battery life
- Lifting speed keeps smooth regardless of loading weight, which is safe to use
- The maintenance-free design ensures security, reduces service cost
- Three different types of forks are optional
-
MODEL SM-SE2T3M LOAD CAPACITY Q(kg) 2000 LOAD CENTER c(mm) 500 WHEEL BASE Y(mm) 1145 WEIGHT (WITH BATTERY) kg 265-350 WHEEL SIZE, FRONT (mm) φ80×70 WHEEL SIZE, REAR (mm) φ180×50 HEIGHT, MAST LOWERED h1(mm) 2088 LIFTING HEIGHT h3(mm) 3000 MAST HEIGHT AT MAX. LIFTING HEIGHT h4(mm) 2088 LOWERED FORK HEIGHT h13(mm) 90 OVERALL LENGTH l1(mm) 1505 OVERALL WIDTH b1(mm) 1080~1420 FORK LENGTH l(mm) 1150 FORK WIDTH b5(mm) 240~660 MAST GROUND CLEARANCE m1(mm) 28 AISLE WIDTH FOR PALLET1000x1200 (1200 CROSSWAYS) Ast(mm) 1705 AISLE WIDTH FOR PALLET 800×1200 (1200 LENGTHWAYS) Ast(mm) 1755 TURNING RADIUS Wa(mm) 1210 LIFTING SPEED,LADEN/UNLADEN m/s 150 LOWER SPEED,LADEN/UNLADEN m/s MANUAL LIFTING MOTOR POWER kW 1.6 BATTERY VOLTAGE/NOMINAL CAPACITY V/Ah 12 – 150
